Chapter: Introduction
16 M10-17313-EN
Legend for Figure 1
Label Component
1Ballscrew cover
2Top plate
3Column cover
4Load cell
5Upper limit switch
6 Limit switch actuator
7Lower limit switch
8 Emergency stop button
9 Frame control panel
10 Bluehill
®
Operator Dashboard (optional)
