Paper
feed
method/
Feed
quantity
Multi-purpose
tray
Capacity 310 sheets (GSM weight 64g/m
2
, total thickness 31mm max.)
*18
1st tray Capacity 580 sheets (GSM weight 64g/m
2
, total thickness 53mm max.)
*19
Expansion
tray unit
(Optional) Capacity 580 sheets (GSM weight 64g/m
2
, total thickness 53mm max.)
*20
Large-
capacity
expansion
tray unit
(Optional) Capacity 580 sheets x 3 trays (GSM weight 64g/m
2
, total thickness 53mm
max.)
Paper
feed
method/
Output
capacity
Face down 620 sheets max. (GSM weight 64g/m
2
)
Face up 300 sheets max. (GSM weight 64g/m
2
)
Assured print range 6.35mm from the paper edge (excluding special paper such as envelopes, etc.)
Print accuracy Write position accuracy ±2mm; paper slant: ±1mm/100mm
Image expansion and contraction ±1mm/100mm (GSM weight 80g/m
2
)
Warm-up time Approx. 50s (max.) after power is turned ON (At room temperature 25ºC and rated
voltage)
*21
Average print quantity 25,000 sheets/month
Use environment
conditions
Temperature 10ºC to 32ºC, humidity 20% to 80%RH, max. wet bulb temperature 25ºC
(Environments where high-quality and full color are assured : Temperature 17ºC to
27ºC, humidity 50% to 70%RH)
Consumables and
maintenance products
Consumables, toner cartridge, image drum,
maintenance products, fi xer unit, transfer roller unit, belt unit, paper feed roller set,
waste toner box
Device service life
*22
5 years or 1.5 million pages
*1: The total weight including consumables is approx. 97kg.
*2: The total weight including consumables is approx. 110kg.
*3: CS5000 specifi cations only.
*4: Plain paper, in copy mode print speed is slower for postcards, envelopes, and card stock. Operation may slow down during
continuous printing due to adjustments in machine temperature and image quality.
*5: The mode that prints white before CMYK. If the paper size exceeds B4, the print speed is slower.
*6: Compatible with plain and glossy paper only.
*7: Print quality and paper traction may suffer depending on the paper used and the use environment. Implementing a test print
beforehand is recommended. Consult your supervisor if anything is unclear.
*8: It is not possible to print on glossy paper (except those recommended by Intec), coated paper (Gloss, Matt, Dull, Silk) and
embossed paper. If printing Spot Color white or Spot Color clear using a single color, the K drum will also rotate normally.
*9: For glossy paper, use only those recommended by Intec, when using clear toner. Also, in conditions where the room
temperature is above 25ºC and the humidity is below 60%. Print quality may be reduced in any other environments.
*10: Compatible with Multi-Purpose Tray only.
*11: Compatible with 1st tray and Multi-Purpose Tray only.
*12: Compatible with A4 and letter only.
*13: Compatible with Multi-Purpose Tray only. The paper may curl or crease after printing.
*14: Compatible with Multi-Purpose Tray only.
*15: Nagagata #3, Nagagata #4, Nagagata #40, Yougata #0, Yougata #2, Yougata #4, Younaga #3, Kakugata #2, Kakugata #3,
Kakugata #6, Kakugata #8, C4, C5, DL, COM-9, COM-10 Monarch.
*16: 1st tray, expansion tray unit, large-capacity expansion tray unit: Width 100 to 330mm x length 148 to 457mm.
Multi-Purpose Tray: Width 64 to 330mm x length 90 to 1,321mm. If using Spot Color overprint, length is 182 to 457mm.
*17: 1st tray, expansion tray unit, large-capacity expansion tray unit: Width 100 to 330mm x length 148 to 457mm.
Multi-Purpose Tray: Width 64 to 330mm x length 90 to 483mm.
*18: Postcards x 110, transparencies x 200, envelopes x 40 (GSM weight 85g/m
2
).
*19: Postcards x 210, transparencies x 360.
*20: Postcards x 210.
*21: Does not include compensation operations.
*22: Device service life depends on the customer's use conditions.
CS4000 CS5000
Print
speed*
*4
Color
(1-sided)
CMYK 50 pages/min. (A4 landscape feed), 28 pages/min. (A3
portrait feed)
(If auto paper weight is set)
CMYK+1 color
-
CMYK+Spot Color
white:
45 pages/min.
(A4 landscape
feed),
25 pages/min.
(A3 portrait feed)
CMYK+Spot Color
clear:
18 pages/min.
(A4 landscape feed)
Spot Color overprint
*5
(CMYK+Spot Color white)
-
45 pages/min.
(A4 landscape feed)
6 pages/min.
(A3 portrait feed)
Monochrome (1-sided) 50 pages/min. (A4 landscape feed)
28 pages/min. (A3 portrait feed)
(If auto paper weight is set)
Auto Duplex CMYK Color: 50 pages/min. (A4 landscape feed)
Monochrome: 50 pages/min. (A4 landscape feed)
Color: 28 pages/min. (A3 portrait feed)
Monochrome: 28 pages/min. (A3 portrait feed)
(If auto paper weight is set)
(CMYK+Spot Color
white)
*6
-
*CMYK+Spot Color
white
is compatible with
single color only
45 pages/min.
(A4 landscape
feed),
25 pages/min.
(A3 portrait feed)
Spot Color overprint
(CMYK+Spot Color white)
-
Type of
paper
*7
Paper
quality
*8
Plain, thick paper (glossy
*9
, transparent fi lm
*10
, transparencies
*11
, postcards, labels
*12
,
envelopes
*13
)
Paper size A3NOBI, 13×18", A3WIDE (SRA3), A3, A4WIDE (SRA4), A4, A5, A6, B4, B5, B6, letter,
legal13/13.5/14, Executive,
Statement
*14
, Tabloid Extra, Tabloid, 8K, 16K, envelopes
*15
, postcards,
Japanese double postcards, 4-REN Hagaki, index cards
*14
, B6 half
*14
, custom
*16
GSM paper
weight
1st tray: GSM 52 to 320g/m
2
(ream weight 45 to 275kg)
Expansion tray unit: GSM 52 to 320g/m
2
(ream weight 45 to 275kg)
Large-capacity expansion tray unit: GSM 52 to 320g/m
2
(ream weight 45 to 275kg)
Multi-Purpose Tray: GSM 52 to 400g/m
2
(ream weight 45 to 343kg)
Auto
Duplex
Functions
Paper size A3NOBI, 13×18", A3WIDE (SRA3), A3, A4WIDE (SRA4), A4, A5, A6 portrait feed, B4,
B5, B6, letters, legal13/13.5/14), Executive,
Statement, Tabloid Extra, Tabloid, 8K, 16K, postcards, Japanese double postcards,
4-REN Hagaki, Custom
*17
GSM paper
weight
1st tray: GSM 64 to 320g/m
2
(ream weight 55 to 275kg)
Expansion tray unit: GSM 64 to 320g/m
2
(ream weight 55 to 275kg)
Large-capacity expansion tray unit: GSM 64 to 320g/m
2
(ream weight 55 to 275kg)
Multi-Purpose Tray: GSM 64 to 320g/m
2
(ream weight 55 to 275kg)
