- 128 - - 129 -

Speci cations
Main speci cations
Model CS4000: N36100A(120V), N36100B(230V), N36100C(100V)
CS5000: N36101A(120V), N36101B(230V), N36101C(100V)
CPU CS4000: ARM Processor (1GHz)
CS5000: ARM Processor (1.2GHz)
RAM (standard/
max.)
2GB/2GB
Weight CS4000: Approx. 82kg (not including consumables)
*1
CS5000: Approx. 91kg (not including consumables)
*2
Power 110 to 127 VAC (Range 99 to 140 VAC), 50/60 Hz ± 2%
220 to 240 VAC (Range 198 to 264 VAC), 50/60 Hz ± 2%
Power consumption During operations: 1,500W max./Average 1,100W
During standby: Average 40W
In power save mode
In power save mode: 30W max.
In sleep mode: 4W max. (factory settings)
In Auto Power OFF: 0.4W max.
* The product does not consume power when the main power switch is OFF, even if the power plug is
inserted into the outlet.
Use environment
conditions
Temperature 10ºC to 32ºC, humidity 20% to 80%RH
Max. wet bulb temperature 25ºC (Environments where high-quality and full color are
assured : Temperature 17ºC to 27ºC, humidity 50% to 70%RH)
Network connection 1000BASE-T/100BASE-TX/10BASE-T (Factor y settings 100BASE-TX/10BASE-T)
Local connections USB2.0 interface (Hi-Speed USB supported)
Display 4.3" high-resolution color LCD (480x272dots)
Compatible OS Windows 8.1/Windows 8/Windows 7/Windows Vista/Windows XP/Windows Server 2012 R2/
Windows Server 2012/
Windows Server 2008 R2/Windows Server 2008/Windows Server 2003
, Mac OS X 10.5 to 10.8
For details, see the operations environment.
Print method CS4000: Dry electronic photo method using 4 continuous digital LED heads
CS5000: Dry electronic photo method using 5 continuous digital LED heads
Resolution Print
resolution
1200 x 1200dpi (2 shades) / 1200 x 600dpi (16 shades) - interpolated 4800 /
600 x 600dpi (2 shades)
LED dot pitch 1200dpi
Print colors Yellow, magenta, cyan, black, white*
3
, clear*
3
Print languages PostScript3, PCL6 (PCLXL3.0, PCL5c), PDF1.7, IBM PPR, EPSON FX

Basic Windows Functions
This section explains the procedures for displaying the drivers setup window from the [Printers]/[Printer
and Fax] folder for OS other than Windows 7, which is used as an example in this manual.
Memo

The Windows 8.1/Windows Server 2012 R2 procedure is the same as for Windows 8/Windows Server 2012.

If installing multiple drivers, the icon will be displayed for each driver in the [Printers]/[Printer and Fax] folder. Use the
following procedure for the drivers to be set up and checked.
Displaying the Properties
Window

Windows 8/Windows Server 2012
1
Click [Setup], and select [Control
panel]> [Show devices and printers].
2
Right-click the INTEC CS5000 icon, and
select [Printing Preferences].

Windows Vista/Windows Server
2008
1
Click the [Start] button, and select
[Control panel]> [Printers].
2
Right-click the INTEC CS5000 icon, and
select [Preferences].

Windows XP/Windows Server
2003
1
Click [Start], and then select [Printers
and Fax].
2
Right-click the INTEC CS5000 icon, and
select [Printing Preferences].
Displaying the print setup
window

Windows 8/Windows Server 2012
1
Click [Setup], and select [Control
panel]> [Show devices and printers].
2
Right-click the INTEC CS5000 icon, and
select [Printing Preferences].

Windows Vista/Windows Server
2008
1
Click the [Start] button, and select
[Control panel]> [Printers].
2
Right-click the INTEC CS5000 icon, and
select [Printing preferences].

Windows XP/Windows Server
2003
1
Click [Start], and then select [Printers
and Fax].
2
Right-click the INTEC CS5000 icon, and
select [Printing preferences].
