ASSIST PLUS – Operating instructions V02 Programming
26 INTEGRA Biosciences AG
Source
(Reser-
voir)
Type Sets the source container where the initial sample is
aspirated from (Reservoir or Plate). Only INTEGRA
reservoirs can be used as Reservoir type.
Tracking If Reservoir is selected and Tracking is active, the pipette
automatically adjusts the pipetting height according to the
defined tip immersion depth. Set the:
• Reservoir type, see “8.2
Consumables” on page 50.
• Start volume: the filling volume that is currently in the
INTEGRA reagent reservoir.
• Tip immersion: the approx. immersion depth of the pipette
tips (2-3 mm are recommended).
Source
(Plate)
Type Sets the source container where the initial sample is
aspirated from (Reservoir or Plate).
Plate Select the deck position (B or C) as location for the source
plate.
Column/Row Select the column/row of the plate where the sample is
aspirated from. Note: the column/row number depends on
plate orientation.
Clear Height Sets the travel height at which the GripTips move above the
plates.
Source
(Gene-
ral)
Height Sets the sample aspiration height of the source container.
Note: only visible if Tracking is switched off.
Aspirate Sets the sample volume that will be transferred from well to
well.
Asp Speed Sets speed uniquely for aspiration (1 = low, 10 = fast).
Mixing Mixes the sample in the source container before the first
aspiration.
If activated, define Mix volume, Mix Speed and number of
Mix Cycles.
Options Steps Description of Serial Dilution
