ASSIST PLUS – Operating instructions V02 Programming
www.integra-biosciences.com 27
Target Plate Sets the destination plate position (B or C).
Clear Height Sets the travel height at which the GripTips move from well
to well on the target plate. Note: only visible if not yet defined
under source.
First Column
or First Row
Sets the destination for the first transfer of the serial dilution
(column 1-24 or row A-P).
Count Sets the number of columns or rows to dilute (1-n, including
the first column/row).
Height This is the dispense, mix and aspiration height in the target
container. If Tip Travel is enabled, this height is used as base
from which the tip travel starts for dispensing, see “7.8
Tip
travel distances” on page 47.
Mix Sets the mixing volume after dispensing. It does not affect
the transfer volume.
Mix Speed Sets the mixing speed (1 = low, 10 = fast).
Mix Cycles Sets the number of mixes per well (1-30).
Mix with
Blowout
Sets a Blowout/Blowin after the mix step is completed.
Last
Aspirate
Location Sets the destination of the last aspirate:
• Reservoir: the last aspirate is dispensed in the reservoir.
• Tip: last aspirate remains in the GripTips and is purged
automatically with the tip ejection.
• Waste: the last aspirate is dispensed in the selected
column/ row of the selected plate.
BlowOut at The BlowOut is following the last dispense and expels extra
air to discharge residual liquid from the tips. Adjust the blow
out height, see “5.4
Adjust heights and positions” on page 22.
Options Steps Description of Serial Dilution
