Datasheet, Volume 1 107
Processor Pin and Signal Information
8 Processor Pin and Signal
Information
8.1 Processor Pin As signments
• Ta b l e 8-1, Tab l e 8-2 and Tabl e 8-3 all pins ordered alphabetically for the rPGA988B
BGA1224 and BGA1023 package respectively.
• Figure 8-1, Figure 8-2, Figure 8-3 and Figure 8-4 show the Top-Down view of the
rPGA988B pinmap.
• Figure 8-5, Figure 8-6, Figure 8-7 and Figure 8-8 show the Top-Down view of the
BGA1224 ballmap.
• Figure 8-9, Figure 8-10, Figure 8-11 and Figure 8-12 show the Top-Down view of
the BGA1023 ballmap.
