Introduction
18 Datasheet, Volume 1
1.3.6 Processor Graphics Controller
• Rapid Memory Power Management RMPM – CxSR
• Graphics Performance Modulation Technology (GPMT)
• Intel Smart 2D Display Technology (Intel S2DDT)
• Graphics Render C-State (RC6)
•Intel
®
Seamless Display Refresh Rate Switching with eDP port
1.4 Thermal Management Support
• Digital Thermal Sensor
•Intel
®
Adaptive Thermal Monitor
• THERMTRIP# and PROCHOT# support
• On-Demand Mode
• Open and Closed Loop Throttling
• Memory Thermal Throttling
• External Thermal Sensor (TS-on-DIMM and TS-on-Board)
• Render Thermal Throttling
• Fan speed control with DTS
1.5 Package
• The processor is available on two packages:
— A 37.5 x 37.5 mm rPGA package (rPGA988B)
— A 31 x 24 mm BGA package (BGA1023 or BGA1224)
1.6 Terminology
Term Description
BLT Block Level Transfer
CRT Cathode Ray Tube
DDR3 Third-generation Double Data Rate SDRAM memory technology
DMA Direct Memory Access
DMI Direct Media Interface
DP DisplayPort*
DTS Digital Thermal Sensor
eDP* Embedded DisplayPort*
Enhanced Intel
SpeedStep
®
Technology
Technology that provides power management capabilities to laptops.
