DDR Data Swizzling
Datasheet, Volume 1 171
§ §
Table 9-2. DDR Data Swizzling
Table – Channel B
Pin Name
Pin
Number
rPGA
Pin
Number
BGA1023
Pin
Number
BGA1224
MC
Pin
Name
SB_DQ[0] C9 AL4 AL4 DQ03
SB_DQ[1] A7 AL1 AK3 DQ02
SB_DQ[2] D10 AN3 AP3 DQ05
SB_DQ[3] C8 AR4 AR2 DQ04
SB_DQ[4] A9 AK4 AL2 DQ00
SB_DQ[5] A8 AK3 AK1 DQ01
SB_DQ[6] D9 AN4 AP1 DQ06
SB_DQ[7] D8 AR1 AR4 DQ07
SB_DQ[8] G4 AU4 AV3 DQ11
SB_DQ[9] F4 AT2 AU4 DQ10
SB_DQ[10] F1 AV4 BA4 DQ12
SB_DQ[11] G1 BA4 BB1 DQ14
SB_DQ[12] G5 AU3 AV1 DQ08
SB_DQ[13] F5 AR3 AU2 DQ09
SB_DQ[14] F2 AY2 BA2 DQ13
SB_DQ[15] G2 BA3 BB3 DQ15
SB_DQ[16] J7 BE9 BC2 DQ19
SB_DQ[17] J8 BD9 BF7 DQ18
SB_DQ[18] K10 BD13 BF11 DQ20
SB_DQ[19] K9 BF12 BJ10 DQ22
SB_DQ[20] J9 BF8 BC4 DQ17
SB_DQ[21] J10 BD10 BH7 DQ16
SB_DQ[22] K8 BD14 BH11 DQ21
SB_DQ[23] K7 BE13 BG10 DQ23
SB_DQ[24] M5 BF16 BJ14 DQ25
SB_DQ[25] N4 BE17 BG14 DQ30
SB_DQ[26] N2 BE18 BF17 DQ29
SB_DQ[27] N1 BE21 BJ18 DQ28
SB_DQ[28] M4 BE14 BF13 DQ24
SB_DQ[29] N5 BG14 BH13 DQ31
SB_DQ[30] M2 BG18 BH17 DQ27
SB_DQ[31] M1 BF19 BG18 DQ26
SB_DQ[32] AM5 BD50 BH49 DQ36
SB_DQ[33] AM6 BF48 BF47 DQ38
SB_DQ[34] AR3 BD53 BH53 DQ34
SB_DQ[35] AP3 BF52 BG50 DQ35
SB_DQ[36] AN3 BD49 BF49 DQ39
SB_DQ[37] AN2 BE49 BH47 DQ37
SB_DQ[38] AN1 BD54 BF53 DQ33
SB_DQ[39] AP2 BE53 BJ50 DQ32
SB_DQ[40] AP5 BF56 BF55 DQ44
SB_DQ[41] AN9 BE57 BH55 DQ43
SB_DQ[42] AT5 BC59 BJ58 DQ47
SB_DQ[43] AT6 AY60 BH59 DQ46
SB_DQ[44] AP6 BE54 BJ54 DQ40
SB_DQ[45] AN8 BG54 BG54 DQ42
SB_DQ[46] AR6 BA58 BG58 DQ45
SB_DQ[47] AR5 AW59 BF59 DQ41
SB_DQ[48] AR9 AW58 BA64 DQ51
SB_DQ[49] AJ11 AU58 BC62 DQ49
SB_DQ[50] AT8 AN61 AU62 DQ52
SB_DQ[51] AT9 AN59 AW64 DQ48
SB_DQ[52] AH11 AU59 BA62 DQ53
SB_DQ[53] AR8 AU61 BC64 DQ50
SB_DQ[54] AJ12 AN58 AU64 DQ55
SB_DQ[55] AH12 AR58 AW62 DQ54
SB_DQ[56] AT11 AK58 AR64 DQ56
SB_DQ[57] AN14 AL58 AT65 DQ58
SB_DQ[58] AR14 AG58 AL64 DQ61
SB_DQ[59] AT14 AG59 AM65 DQ62
SB_DQ[60] AT12 AM60 AR62 DQ57
SB_DQ[61] AN15 AL59 AT63 DQ59
SB_DQ[62] AR15 AF61 AL62 DQ63
SB_DQ[63] AT15 AH60 AM63 DQ60
Table 9-2. DDR Data Swizzling
Table – Channel B
Pin Name
Pin
Number
rPGA
Pin
Number
BGA1023
Pin
Number
BGA1224
MC
Pin
Name
