Processor Pin and Signal Information
Datasheet, Volume 1 127
Table 8-2. BGA1224 Processor Ball
List by Ball Name
Ball Name Ball # Buffer Type Dir
BCLK D5 Diff Clk I
BCLK# C6 Diff Clk I
BCLK_ITP K63 Diff Clk I
BCLK_ITP# K65 Diff Clk I
BPM#[0] C62 Asynch CMOS I/O
BPM#[1] D61 Asynch CMOS I/O
BPM#[2] E62 Asynch CMOS I/O
BPM#[3] F63 Asynch CMOS I/O
BPM#[4] D59 Asynch CMOS I/O
BPM#[5] F61 Asynch CMOS I/O
BPM#[6] F59 Asynch CMOS I/O
BPM#[7] G60 Asynch CMOS I/O
CATERR# H53 Asynch CMOS O
CFG[0] B57 CMOS I
CFG[1] D57 CMOS I
CFG[2] B55 CMOS I
CFG[3] A54 CMOS I
CFG[4] A58 CMOS I
CFG[5] D55 CMOS I
CFG[6] C56 CMOS I
CFG[7] E54 CMOS I
CFG[8] J54 CMOS I
CFG[9] G56 CMOS I
CFG[10] F55 CMOS I
CFG[11] K55 CMOS I
CFG[12] F57 CMOS I
CFG[13] E58 CMOS I
CFG[14] H57 CMOS I
CFG[15] H55 CMOS I
CFG[16] D53 CMOS I
CFG[17] K57 CMOS I
DBR# H61 Asynch CMOS O
DC_TEST_A4 A4 N/A
DC_TEST_A62 A62 N/A
DC_TEST_A64 A64 N/A
DC_TEST_B3 B3 N/A
DC_TEST_B63 B63 N/A
DC_TEST_B65 B65 N/A
DC_TEST_BF1 BF1 N/A
DC_TEST_BF65 BF65 N/A
DC_TEST_BG2 BG2 N/A
DC_TEST_BG64 BG64 N/A
DC_TEST_BH1 BH1 N/A
DC_TEST_BH3 BH3 N/A
DC_TEST_BH63 BH63 N/A
DC_TEST_BH65 BH65 N/A
DC_TEST_BJ2 BJ2 N/A
DC_TEST_BJ4 BJ4 N/A
DC_TEST_BJ62 BJ62 N/A
DC_TEST_BJ64 BJ64 N/A
DC_TEST_C2 C2 N/A
DC_TEST_C64 C64 N/A
DC_TEST_D1 D1 N/A
DC_TEST_D65 D65 N/A
DMI_RX#[0] N10 DMI I
DMI_RX#[1] R10 DMI I
DMI_RX#[2] R8 DMI I
DMI_RX#[3] U10 DMI I
DMI_RX[0] N8 DMI I
DMI_RX[1] T9 DMI I
DMI_RX[2] R6 DMI I
DMI_RX[3] U8 DMI I
DMI_TX#[0] N4 DMI O
DMI_TX#[1] R4 DMI O
DMI_TX#[2] P1 DMI O
DMI_TX#[3] U6 DMI O
DMI_TX[0] N2 DMI O
DMI_TX[1] R2 DMI O
DMI_TX[2] P3 DMI O
DMI_TX[3] T5 DMI O
DPLL_REF_CLK AJ4 Diff Clk I
DPLL_REF_CLK# AJ2 Diff Clk I
eDP_AUX AE4 eDP I/O
eDP_AUX# AE2 eDP I/O
eDP_COMPIO AC2 Analog I
eDP_HPD# AE8 Asynch CMOS I
eDP_ICOMPO AB1 Analog I
eDP_TX#[0] AG2 eDP O
eDP_TX#[1] AF1 eDP O
eDP_TX#[2] AE6 eDP O
eDP_TX#[3] AG6 eDP O
eDP_TX[0] AG4 eDP O
eDP_TX[1] AF3 eDP O
eDP_TX[2] AF7 eDP O
eDP_TX[3] AG8 eDP O
FDI_INT AD9 Asynch CMOS I
Table 8-2. BGA1224 Processor Ball
List by Ball Name
Ball Name Ball # Buffer Type Dir
