Thermal Management
68 Datasheet, Volume 1
Table 5-3. Package Turbo Parameters (Sheet 1 of 2)
Segment Symbol Package Turbo Parameter Min
H/W
Default
Max Units Notes
Extreme
Edition
(XE)
Turbo Tim e
Parameter
(package)
Processor turbo long duration time
window
(POWER_LIMIT_1_TIME in
TURBO_POWER_LIMIT MSR 0610h
bits [23:17])
N/A 1 N/A s
10, 11,
14
Long P
(package)
'Long duration' turbo power limit
(POWER_LIMIT_1 in
TURBO_POWER_LIMIT MSR 0610h
bits [14:0])
N/A 55 N/A W
10,12,13,
14
Short P
(package)
'Short duration' turbo power limit
(POWER_LIMIT_2 in
TURBO_POWER_LIMIT MSR 0610h
bits [46:32])
N/A 1.25 x 55 N/A W
10, 14,
15
Quad Core
SV
Turbo Tim e
Parameter
(package)
Processor turbo long duration time
window
(POWER_LIMIT_1_TIME in
TURBO_POWER_LIMIT MSR 0610h
bits [23:17])
0.001 1 64 S
10, 11,
14
Long P
(package)
'Long duration' turbo power limit
(POWER_LIMIT_1 in
TURBO_POWER_LIMIT MSR 0610h
bits [14:0])
40 45 48 W
10,12,13,
14
Short P
(package)
'Short duration' turbo power limit
(POWER_LIMIT_2 in
TURBO_POWER_LIMIT MSR 0610h
bits [46:32])
40 1.25 x 45 60 W
10, 14,
15
Dual Core
SV
Turbo Tim e
Parameter
(package)
Processor turbo long duration time
window
(POWER_LIMIT_1_TIME in
TURBO_POWER_LIMIT MSR 0610h
bits [23:17])
0.001 1 64 S
10, 11,
14
Long P
(package)
'Long duration' turbo power limit
(POWER_LIMIT_1 in
TURBO_POWER_LIMIT MSR 0610h
bits [14:0])
28 35 36 W
10, 12,
13, 14
Short P
(package)
'Short duration' turbo power limit
(POWER_LIMIT_2 in
TURBO_POWER_LIMIT MSR 0610h
bits [46:32])
28 1.25 x 35 44 W
10, 14,
15
Low
Voltage
Turbo Tim e
Parameter
(package)
Processor turbo long duration time
window
(POWER_LIMIT_1_TIME in
TURBO_POWER_LIMIT MSR 0610h
bits [23:17])
0.001 1 32 S
10, 11,
14
Long P
(package)
'Long duration' turbo power limit
(POWER_LIMIT_1 in
TURBO_POWER_LIMIT MSR 0610h
bits [14:0])
24 25 28 W
10, 12,
13, 14
Short P
(package)
'Short duration' turbo power limit
(POWER_LIMIT_2 in
TURBO_POWER_LIMIT MSR 0610h
bits [46:32])
24 1.25 x 25 36 W
10, 14,
15
