Datasheet, Volume 1 99
Electrical Specifications
Notes:
1. The current supplied to the SO-DIMM modules is not included in this specification.
Note: Long term reliability cannot be assured in conditions above or below Max/Min functional limits.
Note: Long term reliability cannot be assured in conditions above or below Max/Min functional limits.
Table 7-7. Memory Controller (V
DDQ
) Supply DC Voltage and Current Specifications
Symbol Parameter Min Typ Max Unit Note
V
DDQ
(DC+AC)
Processor I/O supply voltage for
DDR3 (DC + AC specification)
—1.5— V
TOL
DDQ
V
DDQ
Tol era nc e DC = ± 3%
AC= ±2%
AC+DC= ±5%
%
I
CCMAX_VDDQ
Max Current for V
DDQ
Rail — — 5 A 1
I
CCAVG_VDDQ
(Standby)
Average Current for V
DDQ
Rail
during Standby
— 66 133 mA
Table 7-8. System Agent (V
CCSA
) Supply DC Voltage and Current Specifications
Symbol Parameter Min Typ Max Unit Note
V
CCSA
Voltage for the System Agent and
V
CCSA_SENSE
0.75 — 0.90 V
TOL
CCSA
V
CCSA
Tolerance AC+DC= ±5% %
I
CCMAX_VCCSA
Max Current for V
CCSA
Rail — — 6 A
I
CCTDC_VCCSA
Thermal Design Current (TDC) for
V
CCSA
Rail
—— 6A
Slew Rate Voltage Ramp rate (dV/dT) 0.5 — 10 mV/us
Table 7-9. Processor PLL (V
CCPLL
) Supply DC Voltage and Current Specifications
Symbol Parameter Min Typ Max Unit Note
V
CCPLL
PLL supply voltage (DC + AC
specification)
—1.8 vV
TOL
CCPLL
V
CCPLL
Tolerance AC+DC= ±5% %
I
CCMAX_VCCPLL
Max Current for V
CCPLL
Rail — — 1.2 A
I
CCTDC_VCCPLL
Thermal Design Current (TDC) for
V
CCPLL
Rail
——1.2A
