Mechanical Drawings
52 Intel® 3210 and 3200 Chipset Thermal/Mechanical Design Guide
Figure B-7. Intel
®
3210 and 3200 Chipset Reference Thermal Solution - Fastener Nut
8 7 6 5 4 3 2
H G F E D C B A
8 7 6 5 4 3 2 1
H G F E D C B A
A A
B
B
THIS DRAWING CONTAINS INTEL CORPORAT ION CONFIDENTIAL INFORMATION. IT IS DISCLOSED IN CONFIDENCE AND ITS CONT ENTS MAY NOT BE DISCLOSED, REPRODUCED, DI SPLAYED OR MODIFIED, WITHOUT THE PRI OR WRITTEN CONSENT OF INTEL CORPORATION.
REVISION HISTORY
ZONE REV DESCRIPTION DATE APPROVED
- A INITIAL DV RELEASE 03/09/07 KJC
B3 B CHANGED COLLAR HT FROM 2 TO 4 05/09/07 KJC
1 PRODUCTION RELEASE 06/20/07 KJC
D92621 1 1
DWG. NO SHT. REV
DEPARTMENT
R
2200 MISSION COLLEGE BLVD. P.O. BOX 58119 SANTA CLARA, CA 95052-8119
PST
TITLE
BONE TRAIL, FASTNER, NUT
SIZE DRAWING NUMBER REV
A1 D92621 1
SCALE:
15
DO NOT SCALE DRAWING
SHEET
1
OF
1
SEE NOTESSEE NOTES FINISHMATERIAL 03/09/07P.BORNEMANN DATEAPPROVED BY 03/09/07R.AOKI 03/09/07A.VALPIANI DATECHECKED BY 03/09/07K.CEURTER DATEDRAWN BY 03/09/07K.CEURTER DATEDESIGNED BY
UNLESS OTHERWISE SPECIFIED
INTERPRET DIMENSIONS AND TOLERANCES IN ACCORDANCE WITH ASME Y14.5M-1994
DIMENSIONS ARE IN MILLIMETERS
ALL UNTOLERANCED LINEAR
DIMENSIONS ± 0.1
ANGLES ±0.5
THIRD ANGLE PROJECTION
4 0.1
5 0.1
0.13 A B
6 0.25
0.13 A B
2.71
B 57 0.01
A
A
A
()62
NOTES: 1. USE PEM PART NUMBER = OR INTEL APPROVED ALTERNATE 2. DIMENSIONS ARE IN MILLIMETERS 3. MATERIAL: - LOW CARBON STEEL 4. FINISH: - ZINC PLUS CLEAR CHROMATE PER ASTM B633 COLORLESS
5 . CRITICAL TO FUNCTION
6. REFERENCE AND NON-DIMENSIONED FEATURES MAY BE MODIFIED PER INTEL APPROVAL
RECESS FOR #2 PHILLIPS DRIVER
SECTION A-A
6-32 UNC - 2B TAP 5
#36 DRILL ( 2.71 ) THRU -( 1 ) HOLE
SECTION B-B
