Thermal/Mechanical Reference Design
26 Dual-Core Intel® Xeon® Processor 5100 Series Thermal/Mechanical Design Guide
Note: The thermal specifications shown in this graph are for reference only. Refer to the
Dual-Core Intel
®
Xeon
®
Processor 5100 Series Datasheet for the Thermal Profile
specifications. In case of conflict, the data information in the datasheet supersedes any
data in this figure.
Figure 2-10. Thermal Profile for the Dual-Core Intel® Xeon® Processor 5110/5120/5130/
5140/5150
TCASE_MAX@TDP
Y = 0.385*x +40.0
45
50
55
60
65
70
20 25 30 35 40 45 50 55 60 65
Power [W]
Temperature [C]
TCASE_MAX@TDP
Y = 0.385*x +40.0
45
50
55
60
65
70
20 25 30 35 40 45 50 55 60 65
Power [W]
Temperature [C]
