Introduction
1 Introduction
1.1 Objective
This document describes the reference thermal solution and design parameters
required for Dual-Core Intel
®
Xeon
®
Processor 5100 Series. It is also the intent of this
document to comprehend and demonstrate the processor cooling solution features and
requirements. Furthermore, this document provides an understanding of the processor
thermal characteristics, and discusses guidelines for meeting the thermal requirements
imposed on the entire life of the processor. The thermal/mechanical solutions described
in this document are intended to aid component and system designers in the
development and evaluation of processor compatible thermal/mechanical solutions.
1.2 Scope
The thermal/mechanical solutions described in this document pertain only to a
solution(s) intended for use with the Dual-Core Intel Xeon Processor 5100 Series in
1U/Volumetric constrained, 2U, 2U+ and workstation form factors systems. This
document contains the mechanical and thermal requirements of the processor cooling
solution. In case of conflict, the data in the Dual-Core Intel
®
Xeon
®
Processor 5100
Series Datasheet supersedes any data in this document. Additional information is
provided as a reference in the appendices.
1.3 References
Material and concepts available in the following documents may be beneficial when
reading this document.
Table 1-1. Reference Documents
Document Comment
European Blue Angel Recycling Standards http://www.blauer-engel.de
Intel
®
Xeon
®
Processor Family Thermal Test Vehicle User's Guide See Note following table
Intel
®
Xeon
®
Processor Thermal Design Guidelines http://developer.intel.com/
LGA771 Socket Mechanical Design Guide See Note following table
PECI Feature Set Overview See Note following table
Platform Environment Control Interface (PECI) Specification See Note following table
T
RISE
Reduction Guidelines for Rack Servers and Workstations See Note following table
Dual-Core Intel
®
Xeon
®
Processor 5100 Series Datasheet See Note following table
Dual-Core Intel
®
Xeon
®
Processor 5100 Series Enabled Components
Mechanical Models (in IGES and ProE* format)
Available electronically
Dual-Core Intel
®
Xeon
®
Processor 5100 Series Enabled Components
Thermal Models (in Flotherm* and Icepak*)
Available electronically
Dual-Core Intel
®
Xeon
®
Processor 5100 Series Mechanical Models (in
ProE* and IGES model)
Available electronically
Dual-Core Intel
®
Xeon
®
Processor 5100 Series Thermal Models (in
Flotherm* and Icepak*)
Available electronically
Thin Electronics Bay Specification (A Server System Infrastructure [SSI]
Specification for Rack Optimized Servers)
www.ssiforum.com
