Datasheet, Volume 1 75
Electrical Specifications
0 1 0 1 0 1 1 0 5 6 0.67500 1 1 0 1 0 1 1 0 D 6 1.31500
0 1 0 1 0 1 1 1 5 7 0.68000 1 1 0 1 0 1 1 1 D 7 1.32000
0 1 0 1 1 0 0 0 5 8 0.68500 1 1 0 1 1 0 0 0 D 8 1.32500
0 1 0 1 1 0 0 1 5 9 0.69000 1 1 0 1 1 0 0 1 D 9 1.33000
0 1 0 1 1 0 1 0 5 A 0.69500 1 1 0 1 1 0 1 0 D A 1.33500
0 1 0 1 1 0 1 1 5 B 0.70000 1 1 0 1 1 0 1 1 D B 1.34000
0 1 0 1 1 1 0 0 5 C 0.70500 1 1 0 1 1 1 0 0 D C 1.34500
0 1 0 1 1 1 0 1 5 D 0.71000 1 1 0 1 1 1 0 1 D D 1.35000
0 1 0 1 1 1 1 0 5 E 0.71500 1 1 0 1 1 1 1 0 D E 1.35500
0 1 0 1 1 1 1 1 5 F 0.72000 1 1 0 1 1 1 1 1 D F 1.36000
0 1 1 0 0 0 0 0 6 0 0.72500 1 1 1 0 0 0 0 0 E 0 1.36500
0 1 1 0 0 0 0 1 6 1 0.73000 1 1 1 0 0 0 0 1 E 1 1.37000
0 1 1 0 0 0 1 0 6 2 0.73500 1 1 1 0 0 0 1 0 E 2 1.37500
0 1 1 0 0 0 1 1 6 3 0.74000 1 1 1 0 0 0 1 1 E 3 1.38000
0 1 1 0 0 1 0 0 6 4 0.74500 1 1 1 0 0 1 0 0 E 4 1.38500
0 1 1 0 0 1 0 1 6 5 0.75000 1 1 1 0 0 1 0 1 E 5 1.39000
0 1 1 0 0 1 1 0 6 6 0.75500 1 1 1 0 0 1 1 0 E 6 1.39500
0 1 1 0 0 1 1 1 6 7 0.76000 1 1 1 0 0 1 1 1 E 7 1.40000
0 1 1 0 1 0 0 0 6 8 0.76500 1 1 1 0 1 0 0 0 E 8 1.40500
0 1 1 0 1 0 0 1 6 9 0.77000 1 1 1 0 1 0 0 1 E 9 1.41000
0 1 1 0 1 0 1 0 6 A 0.77500 1 1 1 0 1 0 1 0 E A 1.41500
0 1 1 0 1 0 1 1 6 B 0.78000 1 1 1 0 1 0 1 1 E B 1.42000
0 1 1 0 1 1 0 0 6 C 0.78500 1 1 1 0 1 1 0 0 E C 1.42500
0 1 1 0 1 1 0 1 6 D 0.79000 1 1 1 0 1 1 0 1 E D 1.43000
0 1 1 0 1 1 1 0 6 E 0.79500 1 1 1 0 1 1 1 0 E E 1.43500
0 1 1 0 1 1 1 1 6 F 0.80000 1 1 1 0 1 1 1 1 E F 1.44000
0 1 1 1 0 0 0 0 7 0 0.80500 1 1 1 1 0 0 0 0 F 0 1.44500
0 1 1 1 0 0 0 1 7 1 0.81000 1 1 1 1 0 0 0 1 F 1 1.45000
0 1 1 1 0 0 1 0 7 2 0.81500 1 1 1 1 0 0 1 0 F 2 1.45500
0 1 1 1 0 0 1 1 7 3 0.82000 1 1 1 1 0 0 1 1 F 3 1.46000
0 1 1 1 0 1 0 0 7 4 0.82500 1 1 1 1 0 1 0 0 F 4 1.46500
0 1 1 1 0 1 0 1 7 5 0.83000 1 1 1 1 0 1 0 1 F 5 1.47000
0 1 1 1 0 1 1 0 7 6 0.83500 1 1 1 1 0 1 1 0 F 6 1.47500
0 1 1 1 0 1 1 1 7 7 0.84000 1 1 1 1 0 1 1 1 F 7 1.48000
0 1 1 1 1 0 0 0 7 8 0.84500 1 1 1 1 1 0 0 0 F 8 1.48500
0 1 1 1 1 0 0 1 7 9 0.85000 1 1 1 1 1 0 0 1 F 9 1.49000
0 1 1 1 1 0 1 0 7 A 0.85500 1 1 1 1 1 0 1 0 F A 1.49500
0 1 1 1 1 0 1 1 7 B 0.86000 1 1 1 1 1 0 1 1 F B 1.50000
0 1 1 1 1 1 0 0 7 C 0.86500 1 1 1 1 1 1 0 0 F C 1.50500
0 1 1 1 1 1 0 1 7 D 0.87000 1 1 1 1 1 1 0 1 F D 1.51000
0 1 1 1 1 1 1 0 7 E 0.87500 1 1 1 1 1 1 1 0 F E 1.51500
0 1 1 1 1 1 1 1 7 F 0.88000 1 1 1 1 1 1 1 1 F F 1.52000
Table 7-1. VR 12.0 Voltage Identification Definition (Sheet 3 of 3)
VID
7
VID
6
VID
5
VID
4
VID
3
VID
2
VID
1
VID
0
HEX V
CC_MAX
VID
7
VID
6
VID
5
VID
4
VID
3
VID
2
VID
1
VID
0
HEX V
CC_MAX
