Processor Pin and Signal Information
Datasheet, Volume 1 99
SB_DQS[6] AL33 DDR3 I/O
SB_DQS[7] AG35 DDR3 I/O
SB_DQS[8] AN16 DDR3 I/O
SB_DQS#[0] AH6 DDR3 I/O
SB_DQS#[1] AL8 DDR3 I/O
SB_DQS#[2] AP8 DDR3 I/O
SB_DQS#[3] AN12 DDR3 I/O
SB_DQS#[4] AN28 DDR3 I/O
SB_DQS#[5] AR33 DDR3 I/O
SB_DQS#[6] AM33 DDR3 I/O
SB_DQS#[7] AG34 DDR3 I/O
SB_DQS#[8] AN15 DDR3 I/O
RSVD AL16 DDR3 I/O
RSVD AM16 DDR3 I/O
RSVD AP16 DDR3 I/O
RSVD AR16 DDR3 I/O
RSVD AL15 DDR3 I/O
RSVD AM15 DDR3 I/O
RSVD AR15 DDR3 I/O
RSVD AP15 DDR3 I/O
SB_MA[0] AK24 DDR3 O
SB_MA[1] AM20 DDR3 O
SB_MA[2] AM19 DDR3 O
SB_MA[3] AK18 DDR3 O
SB_MA[4] AP19 DDR3 O
SB_MA[5] AP18 DDR3 O
SB_MA[6] AM18 DDR3 O
SB_MA[7] AL18 DDR3 O
SB_MA[8] AN18 DDR3 O
SB_MA[9] AY17 DDR3 O
SB_MA[10] AN23 DDR3 O
SB_MA[11] AU17 DDR3 O
SB_MA[12] AT18 DDR3 O
SB_MA[13] AR26 DDR3 O
SB_MA[14] AY16 DDR3 O
SB_MA[15] AV16 DDR3 O
SB_ODT[0] AL26 DDR3 O
SB_ODT[1] AP26 DDR3 O
SB_ODT[2] AM26 DDR3 O
SB_ODT[3] AK26 DDR3 O
SB_RAS# AP24 DDR3 O
SB_WE# AR25 DDR3 O
SKTOCC# AJ33 Analog O
SM_DRAMPWROK AJ19 Async CMOS I
Table 8-1. Processor Pin List by Pin
Name
Pin Name Pin # Buffer Type Dir.
SM_DRAMRST# AW18 DDR3 O
SM_VREF AJ22 Analog I
TCK M40 TAP I
TDI L40 TAP I
TDO L39 TAP O
THERMTRIP# G35 Async CMOS O
TMS L38 TAP I
TRST# J39 TAP I
UNCOREPWRGOOD J40 Async CMOS I
VCC A12 PWR
VCC A13 PWR
VCC A14 PWR
VCC A15 PWR
VCC A16 PWR
VCC A18 PWR
VCC A24 PWR
VCC A25 PWR
VCC A27 PWR
VCC A28 PWR
VCC B15 PWR
VCC B16 PWR
VCC B18 PWR
VCC B24 PWR
VCC B25 PWR
VCC B27 PWR
VCC B28 PWR
VCC B30 PWR
VCC B31 PWR
VCC B33 PWR
VCC B34 PWR
VCC C15 PWR
VCC C16 PWR
VCC C18 PWR
VCC C19 PWR
VCC C21 PWR
VCC C22 PWR
VCC C24 PWR
VCC C25 PWR
VCC C27 PWR
VCC C28 PWR
VCC C30 PWR
VCC C31 PWR
VCC C33 PWR
VCC C34 PWR
Table 8-1. Processor Pin List by Pin
Name
Pin Name Pin # Buffer Type Dir.
