1.14.1.2.1 System States and Power States
Under ACPI, the operating system directs all system and device power state transitions. The
operating system puts devices in and out of low-power states based on user preferences and
knowledge of how devices are being used by applications. Devices that are not being used can be
turned off. The operating system uses information from applications and user settings to put the
system as a whole into a low-power state.
Table 10 lists the power states supported by the D850MD and D850MV boards along with the
associated system power targets. See the ACPI specification for a complete description of the
various system and power states.
Table 10. Power States and Targeted System Power
Sleeping States
Processor
States Device States
Targeted System
Power
(Note 1)
S0 – working C0 – working D0 – working state Full power > 30 W
S1 – Processor stopped C1 – stop grant D1, D2, D3 – device
specification specific
5 W < power < 52.5 W
S3 – Suspend to RAM.
Context saved to RAM.
No power D3 – no power except for
wake-up logic
Power < 5 W
(Note 2)
S4 – Suspend to disk.
Context saved to disk.
No power D3 – no power except for
wake-up logic
Power < 5 W
(Note 2)
S5 – Soft-off. Context
not saved. Cold boot is
required.
No power D3 – no power except for
wake-up logic
Power < 5 W
(Note 2)
No power to the system No power D3 – no power for wake-up
logic, except when provided
by battery or external source
No power to the system so
that service can be
performed.
Notes:
1. Total system power is dependent on the system configuration, including add-in boards and peripherals powered
by the system chassis’ power supply.
2. Dependent on the standby power consumption of wake-up devices used in the system.
