Intel Desktop Board D850MD/D850MV Technical Product Specification
74
2.9 Jumper Block
CAUTION
Do not move any jumpers with the power on. Always turn off the power and unplug the power
cord from the computer before changing a jumper setting. Otherwise, the board could be
damaged.
Figure 18 shows the location of the jumper block.
OM12329
1
3
J9H2
Figure 18. Location of the Jumper Block
