Intel Desktop Board D850MD/D850MV Technical Product Specification
84
2.14 Environmental
Table 53 lists the environmental specifications for the D850MD and D850MV boards.
Table 53. D850MD/D850MV Board Environmental Specifications
Parameter Specification
Temperature
Nonoperating -40 °C to +70 °C
Operating 0 °C to +55 °C
Shock
Unpackaged 30 g trapezoidal waveform
Velocity change of 170 inches/second
Packaged Half sine 2 millisecond
Product Weight (pounds) Free Fall (inches) Velocity Change (inches/sec)
<20 36 167
21 - 40 30 152
41 - 80 24 136
81 - 100 18 118
Vibration
Unpackaged 5 Hz to 20 Hz: 0.01 g² Hz sloping up to 0.02 g² Hz
20 Hz to 500 Hz: 0.02 g² Hz (flat)
Packaged 10 Hz to 40 Hz: 0.015 g² Hz (flat)
40 Hz to 500 Hz: 0.015 g² Hz sloping down to 0.00015 g² Hz
