Intel Desktop Board D850MD/D850MV Technical Product Specification
70
2.8.3 External I/O Connectors
Figure 17 shows the locations of the external I/O connectors.
OM12328
B
10
7
2
1
15
2
1
16
1
D C
10
9
2
1
A
Item Description For more information see:
A Front panel audio Table 43, page 71
B Front panel USB Table 44, page 71
C Auxiliary front panel power/sleep/message-waiting LED Table 45, page 71
D Front panel Table 46, page 72
Figure 17. External I/O Connectors
