Intel D850MVSE - Fan 3 Connector (D850 MV Board Only); Chassis Intrusion Connector; ATX12 V Power Connector; Processor Fan Connector

Technical Reference
61
CAUTION
Use only an ATX12V-compliant power supply with these boards. ATX12V power supplies have
two power leads that provide required supplemental power for the Intel Pentium
4 processor and
the Intel 850 chipset. Always connect the 20-pin and 4-pin leads of the ATX12V power supply to
the corresponding connectors on the D850MD and D850MV boards. Otherwise, the board and the
processor could be damaged.
Do not use a standard ATX power supply. Doing so could damage the board and the processor.
Table 29. Fan 3 Connector (D850MV Board Only)
Pin Signal Name
1 FAN_CNTRL
2 +12 V
3 Reserved
Table 30. Chassis Intrusion Connector
Pin Signal Name
1 Intruder
2 Ground
Table 31. ATX12V Power Connector
Pin Signal Name Pin Signal Name
1 Ground 3 +12 V
2 Ground 4 +12 V
Table 32. Processor Fan Connector
Pin Signal Name
1 Ground
2 +12 V
3 Tachometer (CPU_FAN)
Table 33. Fan 1 Connector
Pin Signal Name
1 FAN_CNTRL
2 +12 V
3 Ground
