Land Listing
76 Quad-Core Intel® Xeon® Processor 5300 Series Datasheet
H29 VSS Power/Other
H3 VSS Power/Other
H30 BSEL1 CMOS
Asynchronous
Output
H4 RSP# Common Clk Input
H5 BR1# Common Clk Input
H6 VSS Power/Other
H7 VSS Power/Other
H8 VSS Power/Other
H9 VSS Power/Other
J1 VTT_OUT Power/Other Output
J10 VCC Power/Other
J11 VCC Power/Other
J12 VCC Power/Other
J13 VCC Power/Other
J14 VCC Power/Other
J15 VCC Power/Other
J16 DP0# Common Clk Input/Output
J17 DP3# Common Clk Input/Output
J18 VCC Power/Other
J19 VCC Power/Other
J2 RESERVED
J20 VCC Power/Other
J21 VCC Power/Other
J22 VCC Power/Other
J23 VCC Power/Other
J24 VCC Power/Other
J25 VCC Power/Other
J26 VCC Power/Other
J27 VCC Power/Other
J28 VCC Power/Other
J29 VCC Power/Other
J3 RESERVED
J30 VCC Power/Other
J4 VSS Power/Other
J5 REQ1# Source Sync Input/Output
J6 REQ4# Source Sync Input/Output
J7 VSS Power/Other
J8 VCC Power/Other
J9 VCC Power/Other
Table 4-2. Land Listing by Land Number
(Sheet 15 of 20)
Pin
No.
Pin Name
Signal
Buffer Type
Direction
K1 LINT0 CMOS
Asynchronous
Input
K2 VSS Power/Other
K23 VCC Power/Other
K24 VCC Power/Other
K25 VCC Power/Other
K26 VCC Power/Other
K27 VCC Power/Other
K28 VCC Power/Other
K29 VCC Power/Other
K3 A20M# CMOS
Asynchronous
Input
K30 VCC Power/Other
K4 REQ0# Source Sync Input/Output
K5 VSS Power/Other
K6 REQ3# Source Sync Input/Output
K7 VSS Power/Other
K8 VCC Power/Other
L1 LINT1 CMOS
Asynchronous
Input
L2 TESTHI11 Power/Other Input
L23 VSS Power/Other
L24 VSS Power/Other
L25 VSS Power/Other
L26 VSS Power/Other
L27 VSS Power/Other
L28 VSS Power/Other
L29 VSS Power/Other
L3 VSS Power/Other
L30 VSS Power/Other
L4 A06# Source Sync Input/Output
L5 A05# Source Sync Input/Output
L6 VSS Power/Other
L7 VSS Power/Other
L8 VCC Power/Other
M1 VSS Power/Other
M2 THERMTRIP# Open Drain
Asynchronous
Output
M23 VCC Power/Other
M24 VCC Power/Other
M25 VCC Power/Other
M26 VCC Power/Other
Table 4-2. Land Listing by Land Number
(Sheet 16 of 20)
Pin
No.
Pin Name
Signal
Buffer Type
Direction
