Intel® Server Board S3420GP TPS Connector/Header Locations and Pin-outs
Revision 2.4
Intel order number E65697-010
87
Pin Signal Description Pin
Signal Description
B48 PRSNT2_N NC A48 PERN7 P2E_CPU_S6_RXP<0>
B49 GND GND A49 GND GND
End of x8 End of x8
B50 PETP8 NC A50 RSVD NC
B51 PETN8 NC A51 GND GND
B52 GND GND A52 PERP8 NC
B53 GND GND A53 PERN8 NC
B54 PETP9 NC A54 GND GND
B55 PETN9 NC A55 GND GND
B56 GND GND A56 PERP9 NC
B57 GND GND A57 PERN9 NC
B58 PETP10 NC A58 GND GND
B59 PETN10 NC A59 GND GND
B60 GND GND A60 PERP10 NC
B61 GND GND A61 PERN10 NC
B62 PExP11 NC A62 GND GND
B63 PETN11 NC A63 GND GND
B64 GND GND A64 PERP11 NC
B65 GND GND A65 PERN11 NC
B66 PETP12 NC A66 GND GND
B67 PETN12 NC A67 GND GND
B68 GND GND A68 PERP12 NC
B69 GND GND A69 PERN12 NC
B70 PETP13 NC A70 GND GND
B71 PETN13 NC A71 GND GND
B72 GND GND A72 PERP13 NC
B73 GND GND A73 PERN13 NC
B74 PETP14 NC A74 GND GND
B75 PETN14 NC A75 GND GND
B76 GND GND A76 PERP14 NC
B77 GND GND A77 PERN14 NC
B78 PETP15 NC A78 GND GND
B79 PETN15 NC A79 GND GND
B80 GND GND A80 PERP15 NC
B81 PRSNT2_N NC A81 PERN15 NC
B82
RSVD
NC
A82
GND GND
Three PCI Express* x8 connectors (J2B2, J3B1 and J4B2)
Pin Signal Pin Signal Pin Signal Pin Signal
A1 PRSNT1# B1 +12V A26 HSIP[2] B26 GND
A2 +12V B2 +12V A27 GND B27 HSOP[3]
A3 +12V B3 RESERVED A28 GND B28 HSON[3]
A4 GND B4 GND A29
HSIP[3]
B29 GND
To Next Page
