Platform Management ArchitectureIntel® Server Board SE7520BD2 Technical Product Specification
94 Revision 1.3
Event Filter # Offset Mask Events
9 Degraded Proc 1-2 FRB3 Assert
10 Degraded Proc 1-2 FRB3 Deassert
11 Degraded Proc 1-2 Hot Assert
12 Degraded Proc 1-2 Hot Deassert
13 Critical FP NMI Assert
14 Critical FP NMI Deassert
15 Non Critical SCSI Terminator Fail Assert
16 Non Critical SCSI Terminator Fail Deassert
17 N/A ID Button Assert
18 N/A ID Button Deassert
19 Critical Fan Speed Assert
20 Critical Fan Speed Deassert
21 Non Critical Fan Speed Assert
22 Non Critical Fan Speed Deassert
23 Critical Temperature Assert
24 Critical Temperature Deassert
25 Non Critical Temperature Assert
26 Non Critical Temperature Deassert
27 Critical Proc 1-2 IERR Assert
28 Critical CPU Configuration Error
29 N/A Reserved for Intel
®
Server Management (ISM)
30 N/A Reserved for ISM
4.2.12.2 Alert Over LAN
LAN alerts are sent as SNMP traps in ASF formatted Platform Event Traps to a specified alert
destination. The Alert over LAN feature is used to send either Platform Event Trap alerts or
directed events to a remote system management application, regardless of the state of the
host’s operating system. LAN alerts may be sent over the LAN channel. LAN alerts can be used
by PEF to send out alerts to selected destination whenever an event matches an event filter
table entry. For more information on LAN alerts, see the IPMI Specification v1.5.
4.2.12.3 System Identification in Alerts
The PET alert format used in PPP and LAN Alerting contains a system GUID field that can be
used to uniquely identify the system that raised the alert. In addition, since the PET is carried in
a UDP packet, the alerting system’s IP Address is also present.
4.2.12.4 Platform Alerting Setup
The management controller provides commands via the System Interface that support
setting/retrieving the alerting configuration LAN settings in mBMC NV storage.
The user does not typically deal with filter contents directly. Instead, the Server Setup Utility
provides a user interface that allows the user to select among a fixed set of pre-configured
event filters.
The following list presents the type of alerting configuration options that are provided:
