Intel SE7520BD2 Technical Product Specification

Intel® Server Board SE7520BD2 Technical Product SpecificationPlatform Management Architecture
Revision 1.3 Intel Confidential
93
• Reset
• Diagnostic Interrupt
• Alert
The mBMC maintains an Event Filter table with 30 entries that is used to select the actions to
perform. Also maintained is a fixed/read-only Alert Policy Table entry. No alert strings are
supported.
Note: All Fault/Status LED and ID LED behaviors are driven off of PEF. PEF should not be
disabled and the “as shipped” entry configuration should not be modified or these behaviors will
be changed.
Each time the PEF module receives either an externally or internally generated event message,
it compares the event data against the entries in the event filter table. The mBMC scans all
entries in the table and determines a set of actions to be performed. If a combination of actions
is identified, such as power down, power cycle, and/or reset actions, the action are performed
according to PEF Action Priorities. Action priorities are outlined in the following table.
Note: An action that has changed from delayed to non-delayed, or an action whose delay time
has been reduced has a higher priority. Each generated event is logged to the SEL.
Table 46. PEF Action Priorities
Action Priority Delayed Type Note
Power-down 1 Yes PEF Action
Soft shut-down 2 Yes OEM PEF Action Not executed if a power-down action was
also selected.
Power cycle 3 Yes PEF Action Not executed if a power-down action was
also selected.
Reset 4 Yes PEF Action Not executed if a power-down action was
also selected.
NMI 5 No PEF Action Not executed if a power-down action was
also selected.
PET Alert 6 No PEF Action When selected, always occurs immediately
after detection of a critical event.
IPMB message event 8 No OEM PEF Action When selected, always occurs immediately
after detection of a critical event.
Table 47. mBMC Factory Default Event Filters
Event Filter # Offset Mask Events
1 Non-critical Voltage Assert
2 Non-critical Voltage Deassert
3 Critical Voltage Assert
4 Critical Voltage Deassert
5 Critical PS Soft Fail Assert
6 Critical PS Soft Fail Deassert
7 Critical Proc 1-2 Thermal Trip Assert
8 Critical Proc 1-2 Thermal Trip, Config Error & IERR Deassert
