Connector Pin-out
s and Jumper
BlocksIntel® Se
rver
Board SE7520BD2 Technical Product Specification
140
Revision
1.3
Table 82. SATA Connector
Signa
l Name
Pin
GND 1
S-ATA0_RX_P 2
S-ATA0_RX_N 3
GND 4
S-ATA0_TX_P 5
S-ATA0_TX_N 6
GND 7
Table 83. Battery Holder
Signal Name
Pin
VBAT 1
VBAT 2
GND 3
Table 84. Piezo* Speaker
Signal Name
Pin
SPEAKER_OUT 1
GND 2
Table 85. SCSI L
ED Connector
Signal Name
Pin
GND 1
SCSI_CONN_LED_N 2
SCSI_CONN_LED_N 3
GND 4
Table 86. PLL Multiplier Selection Bit 0
Signal Name
Pin
MCH_PLLSEL0 1
GND 2
Table 87. PLL Multiplier Selection Bit 1
Signa
l Name
Pin
MCH_PLLSEL1
1
GND 2
