Intel® Server Board SE7520BD2 Technical Product Specification Other Useful Information
Revision 1.3 Intel Confidential 159
3. LSI* 320-1,2 RAID controllers fail to recognize the <CTRL-M> needed
to configure during POST
Problem LSI* 320-1, 2 RAID controllers fail to recognize the <CTRL-M> needed
for configuration during POST.
Implication Configuring a RAID Array is impossible.
Workaround None
Status Fixed with BIOS P04.00 and above.
4. LSI* 320-0 ZCR controllers fail to recognize boot on BIOS P03.10 and
P04.
Problem LSI* 320-0 ZCR fails to boot and be recognized at current BIOS levels.
Also, the customer might see the following error message when
attempting to configure: “BIOS configuration utility: adapter number
error, please reboot the system.”
Implication Configuring the Zero Channel RAID (ZCR) is impossible
Workaround The Intel® RAID Contoller SRCZCRX ZCR is fully supported. Refer to
the Tested Hardware and Operating System List rev1.60 on
http://support.intel.com/support/motherboards/server/se7520bd2/sb/CS-
013538.htm for full support details on the Intel equivalent card.
Status Fixed with BIOS P05.00.
5. Intel® Xeon™ Processor E0 stepping SL7DP Processor microcode is
missing
Problem When using an Intel® Xeon™ Processor E0 stepping Sl7DP processor
on the Intel® Server Board SE7520BD2, an error may display indicating
“CPU micro code missing information.”
Implication This issue occurs when the processor microcode is old and needs to be
updated. Such an error warning message indicates that the BIOS
cannot recognize the processor correctly.
Workaround P04.30 BIOS has fixed this issue and includes the new microcode.
Status Fixed.
