Intel SE7520BD2 Technical Product Specification

Intel® Server Board SE7520BD2 Technical Product Specification Product Overview
Revision 1.3 Intel Confidential
25
34 Ground FRAME#
35 IRDY# Ground
36 +3.3V TRDY#
37 DEVSEL# Ground
38 PCIXCAP STOP#
39 LOCK# +3.3V
40 PERR# SMBCLK
41 +3.3V SMBDAT
42 SERR# Ground
43 +3.3V PAR/ECC[0]
44 C/BE[1]# AD[15]
45 AD[14] +3.3V
46 Ground AD[13]
47 AD[12] AD[11]
48 AD[10] Ground
49 M66EN AD[09]
50 Mode 2 Ground
51 Ground Ground
52 AD[08] C/BE[0]#
53 AD[07] +3.3V
54 +3.3V AD[06]
55 AD[05] AD[04]
56 AD[03] Ground
57 Ground AD[02]
58 AD[01] AD[00]
59 +VI/O (3.3V/1.5V) +VI/O (3.3V/1.5V)
60 ACK64#/ECC[1] REQ64#/ECC[6]
61
62
+5V
KEYWAY
KEYWAY
63 Reserved Ground
64 Ground C/BE[7]#
65 C/BE[6]# CBE[5]#/AD[48]
66 CBE[4]#/AD[49] +VI/O (3.3V/1.5V)
67 Ground PAR64/ECC[7]
68 AD[63] AD[62]
69 AD[61] Ground
70 +VI/O (3.3V/1.5V) AD[60]
71 AD[59] AD[58]
72 AD[57] Ground
73 Ground AD[56]
74 AD[55] AD[54]
75 AD[53] +VI/O (3.3V/1.5V)
76 Ground AD[52]
77 AD[51] AD[50]
