Intel® Server Board SE7520BD2 Technical Product SpecificationPlatform Management Architecture
Revision 1.3 Intel Confidential
77
Sensor Name
Sensor
#
Sensor
Type
Event /
Reading
Type
Event Offset
Triggers
Assert /
Deassert
Readable
Value/Offsets
Event Data
PEF
Action
SDR
Record
Type
Tach Fan 3 1Dh
Fan
04h
Threshold
01h
[u][ c,nc] As & De Analog R, T
Fault LED
Action
01
Tach Fan 4 1Eh
Fan
04h
Threshold
01h
[u][ c,nc] As & De Analog R, T
Fault LED
Action
01
Tach Fan 5 1Fh
Fan
04h
Threshold
01h
[u][ c,nc] As & De Analog R, T
Fault LED
Action
01
Tach Fan 6 20h
Fan
04h
Threshold
01h
[u][ c,nc] As & De Analog R, T
Fault LED
Action
01
Proc1 IERR 21h
Processor
07h
Sensor
Specific
6Fh
IERR As – Trig Offset – 02
Proc2 IERR 22h
Processor
07h
Sensor
Specific
6Fh
IERR As – Trig Offset – 02
Proc1 Thermal trip 23h
Processor
07h
Sensor
Specific
6Fh
Thermal Trip As – Trig Offset
Fault LED
Action
02
Proc2 Thermal trip 24h
Processor
07h
Sensor
Specific
6Fh
Thermal Trip As – Trig Offset
Fault LED
Action
02
Proc1 Thermal
Control
25h
Temp
01h
Threshold
01h
[u][ c,nc] As & De Analog Trig Offset
Fault LED
Action
01
Proc2 Thermal
Control
26h
Temp
01h
Threshold
01h
[u][ c,nc] As & De Analog Trig Offset
Fault LED
Action
01
Diagnostic Interrupt
Button
27h
Critical
Interrupt
13h
Sensor
Specific
6Fh
FP NMI Button As – Trig Offset NMI Pulse 02
Chassis Identify
Button
28h
Button
14h
Generic
03h
State Assert As – Trig Offset
ID LED
Action
02
Proc1 Fan 29h
Fan
04h
Threshold
01h
[u,l][ c,nc] As & De Analog R, T
Fault LED
Action
01
Proc2 Fan 2Ah
Fan
04h
Threshold
01h
[u,l][ c,nc] As & De Analog R, T
Fault LED
Action
01
Proc1 Core temp 2Bh
Temp
01h
Threshold
01h
[u,l][ c,nc] As & De Analog R, T
Fault LED
Action
01
Proc2 Core temp 2Ch
Temp
01h
Threshold
01h
[u,l][ c,nc] As & De Analog R, T
Fault LED
Action
01
CPU Configuration
Error
2Dh
Processor
07h
Generic
03h
State Asserted As & De Discrete R, T
Fault LED
Action
02
OEM Type 53h -
OEM Type
53h
N/A N/A N/A N/A N/A N/A N/A
