RFX Load Stick Systems
7005195 Rev A, August 2021
Page 11
INDICATOR OVERVIEW
Indicator Controls (continued)
AZT (Auto Zero Tracking)
The SW RFX Indicator has a feature called Auto Zero Tracking (AZT). AZT corrects
slight zero changes during normal operation. If small weights are added while the
display is at or near zero, the indicator will zero the weights off.
BACKLIGHT
Press the BACKLIGHT key to turn the backlight on and off.
PRINT (SERIAL OUTPUT)
Press the PRINT key to access the PRINT Menu. Press the 1 key to print the screen.
The print format displayed will be the same as the last active screen format used. The
following screenshot is an example of a print layout.
Press the 2 key to access the PRINTING OPTIONS Menu. The following menu is
displayed.
In this example, Print Option 1 - TOGGLE CONTINUOUS (continuous serial output) is
disabled (OFF). The serial output is an externally available signal that can drive a
numeric overhead display, a computer RS-232 input or other peripheral devices
INTERCOMP, U.S.A.
TEL: 763-476-2531
ACTUAL LBS
LF 232 RF 222
LR 241 RR 206
LEFT 52.50% C 51.39%
REAR 49.61% T 901
PRINTING OPTIONS
1: TOGGLE CONTINUOUS
(OFF )
2: SELECT BAUD RATE
To Next Page
