RFX Load Stick Systems
7005195 Rev A, August 2021
Page 19
INDICATOR OVERVIEW
Baseline Setup (continued)
ATTENTION: This feature on the indicator is designed to be used with the
RFX Scale Systems.
RECALL BASELINE SETUP
To recall one of the 99 setups, use the numeric keypad to access a memory location
between 0-99. The following menu will be displayed. In this example, memory location
06 was selected.
Enter the desired memory location number. Press the STORE/ENTER key. The scale
automatically switches to TARGET mode to display the stored setup. Press the
ACTUAL key to view the current weights on the scales. Press the COMPARE key to
display a comparison of the current weights to the target weights.
CLEAR BASELINE SETUP
To clear a setup from a memory location, press the CLEAR key. The following screen
will be displayed. Use the numeric keypad to enter the number of the memory location
to be cleared. Press the STORE/ENTER key to save the entry. To exit, press the
ACTUAL key.
To clear all 99 memory location at one time, enter 00. A second screen will be
displayed to confirm the action. Use the numeric keypad to enter setting 9 to confirm
that all setups are to be cleared from memory. Press any other key to exit without
clearing all 99 memory locations.
RECALL SETUP FROM
MEMORY#1-99: 06
(HIT ACTUAL TO EXIT)
CLEAR SETUP FROM
MEMORY #1-99: 01
(OR ENTER ‘00’ TO
CLEAR ALL SETUPS)
