RFX Load Stick Systems
7005195 Rev A, August 2021
Page 13
INDICATOR OVERVIEW
Indicator Controls (continued)
CENTER OF GRAVITY – CG
ATTENTION: The Center of Gravity feature on the indicator is designed to
be used with the RFX Scale Systems
Press the Center of Gravity (CG) key to access Center of Gravity feature. Press the 1
key for Standard CG. Press the 2 key for Vertical CG.
STANDARD CG
1. Enter the axle width dimension.
2. Enter the wheel base dimensions.
The center of gravity screen is displayed. To exit the CG mode, press the CG key.
Press any key except key I or 2.
VERTICAL CG
1. Position the car level on the scale. Enter the wheel base length.
2. Enter the height the rear wheels will be elevated to for the vertical CG calculation.
The center of gravity screen is displayed. To exit the CG mode, press the CG key.
Press any key except key I or 2.
Refer to the Center of Gravity section for additional information.
NUMERIC KEYPAD
Use the numeric keypad when prompted to enter a number. When the desired number
is entered, press the STORE/ENTER key to save the entry.
The Numeric Keypad can be used to recall target setups when the scale is in Normal
weighing mode. Refer to the Recalling Baseline Setups section for additional
information.
