RFX Load Stick Systems
7005195 Rev A, August 2021
Page 37
OPTIONAL EQUIPMENT INSTALL
1. Remove the two 10-32 screws that are holding the limiting cables on.
2. Unscrew each end of the Load Stick leaving the hex body detached from the
Load Stick.
3. Attach the new hex body by screwing each end of the Load Stick into the hex
body.
4. Reattach the limiting cables using the 10-32 screws to the hex body.
5. Load Stick is now ready for use.
