Intercomp PROFESSIONAL SW777 - Operation; Quick Start and Display Layout

RFX Load Stick Systems
7005195 Rev A, August 2021
Page 21
OPERATION
QUICK START NORMAL MODE
Setup the Load Sticks as described in the following section labeled LOAD STICK
OPERATION. Turn the indicator on. Turn the Load Sticks on. The copyright screen will
be briefly displayed followed by the Change Display Format screen. To display the
Copyright screen for an extended view, press and hold the ON key when turning the
indicator on.
1:OVAL 5:DRAG/RALLY
2:CUP/NW 6:WHT+%
3:ROAD RACE 7: TOTAL
4:DIRT TRK 8:TOTAL+4
All of the formats are fixed display formats with the exception of menu item #3 ROAD
RACE. ROAD RACE is a dynamic display format providing the ability to select which
wheel weights will be totaled and displayed as the selected weight.
DISPLAY LAYOUT
LINES 1-2
Four weights displayed on the first two lines are individual wheel weights. The weights
are displayed in the same pattern as the wheels are installed on the car; Left Front,
Right Front, Left Rear, Right Rear.
A specific scale can be selected or removed by pressing the LF, RF, LR, RR key. Each
time a position key is pressed, a select arrow will turn on and off on the right side of the
weight displayed for a specific scale.
LINE 3
The third line displays the selected weight and the percentage of selected weight to the
total weight.
LINE 4
The fourth line displays the total weight on all four scales.
