OPERATION
INDICATOR DISPLAY LAYOUT OVERVIEW
DEFAULT MODE DESCRIPTION
OVAL TRACK
The following parameters are displayed: Individual Wheel
Weight, Left Side %, Rear %, Cross %, Total Weight
CUP/NW
The following parameters are displayed: Individual Wheel
Weight, Right Side Weight, Front %, Cross %, Total Weight
ROAD RACING
Selection #3 (Road Racing) is a dynamic display format to
select the wheel weights to be totaled and displayed as the
Selected Weight. Individual Wheel Weight, Selected Weight,
Selected % to Total Weight and Total Weight are displayed
DIRT TRACK
The following parameters are displayed: Left Wheel Weight
and %, Rear Weight and %, Cross Weight and %, Rear Bite
DRAG/RALLY
The following parameters are displayed: Individual Wheel
Weight, Front %, Rear % and Total Weight
WHEELS AND
PERCENTAGES
The following parameters are displayed: Individual Wheel
Weight, Front Right %, Left %, Right %, Wedge, Right Rear %
and Total Weight
TOTAL
The TOTAL option will provide a quick snapshot of the total
weight applied to all of the scales in the system
TOTAL + 4
TOTAL + 4 option provides the total weight on all of the scales
and displays the individual weight applied to each scale
