RFX Load Stick Systems
7005195 Rev A, August 2021
Page 15
Press the 3 key to access the Hub Mode options. Refer to the Quick Start (Hub
Mode) section for further instructions on how to configure the system.
INDICATOR OVERVIEW
Special key Combinations (continued)
5. BT
Press the 5 key to access the Bluetooth-APP Link menu.
1) Press the 1 key to ENABLE the Bluetooth APP link for use with the
iRaceWeigh app. Enabling the BT APP feature will also set the Continuous
Output required for the Bluetooth link: Multi-line, 9600 Baud.
2) Press the 2 key to select the DISABLE/STANDBY Bluetooth APP option. The
Continuous Output mode will be disabled.
3) Press the 3 key to reset the Bluetooth-APP Paring.
WARNING: The RESET PAIRING option should only be used when
assistance is required to resolve pairing issues that may occur with
some mobile devices. Refer to the Troubleshooting iRaceWeigh
instructions under the Troubleshooting section for information on how
to reset pairing.
CHANGE DISPLAY FORMAT
To change the display format (the first screen displayed when the indicator is turned
on), press the 1 key and 0 key simultaneously. The following screen will be displayed:
1:OVAL 5:DRAG/RALLY
2:CUP/NW 6:WHT+%
3:ROAD RACE 7: TOTAL
4:DIRT TRK 8: TOTAL + 4
Press a key (1 - 8) to change the format to corresponding description.
BLUETOOTH-APP LINK
1. ENABLE
2. DISABLE/STANDBY
3. RESET PAIRING
