Interlogix NX-595E User Manual

NX-595E User Manual 29
Menu 0 - System Configuration
 0.1 User Configuration
0.1.1 User PIN
0.1.2 User Partition
0.1.3 User Authority
0.2 Time & Date
0.3 Partition Entry Time
0.4 Partition Exit Time
0.5 Phone number configuration
0.6 Voice message recording
User Configuration
The user configuration menu is where user PIN codes are assigned to users. A
user’s PIN code is used to arm and disarm partitions within your security system.
They are generally four digits in length, but can be configured by your service
provider to be six digits in length if this level of security is required. The user
configuration menu is where you also assign partition control and adjust
authorization levels to each user. Assigning partitions to users, determines which
sections (partitions) of the security system a user may access. The authorization
level determines the options available to that user, user authorization is where
you would alter and increase a users authority to become a Master Code.
Master codes can only create, delete or modify user codes with equal or less
authority than themselves.
User PIN – Creating
How to: Configure (set up) a new PIN code for a specific user
Step Example Configure a PIN code of 2580 to user 5
1.
[PIN] Call the NX-595E via an offsite touch-tone phone to begin the session.
2.
Press [0] for system configuration menu.
Press [1] for user configuration menu.
Press [1] for user PIN configuration.
3.
Select a user number followed by # (e.g., User 5.)
4.
Select a new PIN code followed by # (e.g., 2508.)
5.
1
st
star, moves back to user configuration menu.
2
nd
star, moves back to system configuration menu.
3
rd
star, moves back to main menu.
# Disconnects session.

Interlogix NX-595E Specifications

General

Quantity	1
Compatibility	V2 (NX-4, NX-6, NX-8, NX-8E, NX-7, NX-9, NX-10, NX-11)
Operating temperature (T-T)	0 - 49 °C

Weight and Dimensions

Depth	90 mm
Width	220 mm
Height	45 mm
Weight	130 g
Dimensions (WxDxH)	220 x 90 x 45 mm
