Interlogix NX-595E User Manual

NX-595E User Manual 47
All button in the Off row. The corresponding partition number(s) will stop
illuminating red indicating a successful disarm of that partition.
Partition number showing Partition is active, but some zones are not secure
Green Partition is active, and all zones are secure
Yellow Partition is armed in the stay mode
Red Partition is armed in the away mode
Prev – (Previous) will display the previous consecutive event from the internal
event log to what is currently displayed.
Next – Will display the next consecutive event from the internal event log to what
is currently displayed.
Most Recent – Will display the current (latest) existing event from the internal
event log.
Current System faults will be displayed in the System Status window and the
systems past 185 event log can be accessed via the “prev” (previous) button in
the event history window.
Voice Reporting
Alarm phone numbers 1, 2 and 3 will receive a voice message upon the selected
event in the Voice event window being enabled and activated. The voice events
are global for all three alarm phone numbers.

Interlogix NX-595E Specifications

General

Quantity	1
Compatibility	V2 (NX-4, NX-6, NX-8, NX-8E, NX-7, NX-9, NX-10, NX-11)
Operating temperature (T-T)	0 - 49 °C

Weight and Dimensions

Depth	90 mm
Width	220 mm
Height	45 mm
Weight	130 g
Dimensions (WxDxH)	220 x 90 x 45 mm
