Interlogix NX-595E User Manual

NX-595E User Manual 39
Step Example
To record a new zone name, and add this new recording to connected
NX-181xx Voice keypads.
1.
[PIN] Call the NX-595E via an offsite touch-tone phone to begin the session.
2.
Press [0] for system configuration menu.
Press [6] for voice message recording.
Press [4] to record or configure a zone.
3.
Select a zone number to record or configure, followed by #.
4.
 Press #, to record a new zone name.
5.
Record 3 second zone name after the beep.
6.
1
st
star, moves back to step 4, (select a zone number to record.)
2
nd
star, moves back to voice message recording menu.
3
rd
star, moves back to main menu.
# Disconnects session.
Zone Name – library word configuration
To configure a zone name using words from the word library (page 55) instead of
recording your own voice, replace steps 4 and 5 above with the following steps.
Example: Dining room sensor
Up to eight library words can be strung together to achieve your desired phrase.

4.
 Press [2], To configure a new zone name
5
Select library word one, followed by # (e.g., Dining = word 53.)
Select library word two, followed by # (e.g., Room = word 117.)
Select library word three, followed by # (e.g., Sensor = word 121.)
Note: If your system is configured with NX-181xx Voice keypads, you will be
prompted to either copy changed recordings or copy all recordings when exiting
this menu. Copy changed recordings, will only add the latest recordings whilst
selecting copy-all recordings will overwrite all recordings, new and old. Please
contact your security provider to verify how your system is configured.
For multiple recordings, press * once at step 6, which will take you back to
step 4, this will allow additional recordings without exiting the system.
Partition Name – Voice Recording
How to: Record a partition name
Step Example
To record a new partition name, and add this new recording to
connected NX-181xx Voice keypads.
1.
[PIN] Call the NX-595E via an offsite touch-tone phone to begin the session.

Interlogix NX-595E Specifications

General

Quantity	1
Compatibility	V2 (NX-4, NX-6, NX-8, NX-8E, NX-7, NX-9, NX-10, NX-11)
Operating temperature (T-T)	0 - 49 °C

Weight and Dimensions

Depth	90 mm
Width	220 mm
Height	45 mm
Weight	130 g
Dimensions (WxDxH)	220 x 90 x 45 mm
