ZeroWire Building Blocks
Below is the system diagram showing all the key features used to program a
system. The smaller blocks indicate features used by the larger block and should
be programmed first. The number on the bottom right of each block indicates
system capacity (subject to the model).
Areas
a) Area Options
b) Area Timers
c) Area Reporting
Zone Types
- Area Armed
- Area Disarmed
Zone Options
Event Lists
Area Groups
Channels
Channel Groups
Schedule
Channel Groups
Channel Groups
Holidays
Schedules
Permissions
a) Groups
b) Options/Timers
User
a) Main
b) Advanced
Permissions
Schedules
Menus
Area Groups
Channel Groups
Action Groups
Menus
a) Setup
b) Security…
c) History…
d) Communications
e) Times…
Cameras
Actions
Holidays
32
32
32
16
16
16
4
16
16
40
64
4
Zone Type
Zone Options
Area Group
Schedule
User
Communicator
a) General Options
b) Auto Test
c) IP Config
d) Radio
e) Remote Access
f) System Event Reporting
System
a) System Clock
b) System and Siren
c) Timers
d) Maintenance and Test
Zones
a) Profile 1
b) Profile 2
16
Arm/Disarm
User
Schedule
8
Scenes
16
Speech Tokens
UltraSync
Communicator
Event Lists
64
16
Actions
Schedules
Channels
Areas
Devices
16
