Menu 18 - Channel Groups
The ZeroWire provides you powerful and flexible reporting capability through its
Channel feature. They are fully configurable to suit your needs by allowing you to
specify what events to report to single and multiple destinations, with multiple
levels of back up paths.
The relevant menus are:
• Channels
• Channel Groups
• Event List
When a system event occurs, it is routed to the System Event Channel Group
(Communicator\System Event Reporting\System Channels). The Channel Group
will forward the event to each of the Channels it contains. If the event is on the
Channel’s Event List, the Channel will attempt to send the event to the Channel’s
destination.
Example
Channel Group 1
Channel 1
Channel 2
Channel 3
Event List 1
Critical
Alarms
Bypass & Restore
AC Fail
AC Failure
Menu 6 - Communicator > System Event
Reporting > System Channels > 1
Channel Group 1
System Event Reporting
Channel 2
Control Room 2
Event List = 1
Next Channel = 5
Channel 3
Email
Event List = 2
Next Channel = 0
Channel 1
Control Room 1
Event List = 1
Channel Attempts = 3
Next Channel = 4
Menu 18 – Channel Groups
System sends event to Channel Group
Channel Group sends event
to
every Channel it contains
Menu 5 – Channels
Channel 5
Control Room 2
Event List = 1
Next Channel = 0
Channel 4
Control Room 1
Event List = 1
Channel Attempts = 3
Next Channel = 0
Channels 1 and 2 will attempt to send the event
as AC Fail is on the corresponding Event List.
Back up channels 4 and 5 will also attempt to
send the event if they are used.
Channel 3 will NOT send the event as Event List
2 does not include AC Fail events.
Menu 17 – Event Lists
Event List 2
Informational
Open & Closes
Autotest
