Specifications
A-5
A
Memory
Base Optional
1MB of DRAM 8 or 16 MB DRAM SIMM modules
128K of flash 8 to 16 MB Kanji/Katakana flash SIMM module
Printhead
Printed dot size
4420
0.127 mm (0.00492 in square)
4440
0.065 mm (0.00246 in square)
Width 112 mm maximum (4.4 in)
Resolution
4420
8 dots per mm (203 dots per in)
4440
16 dots per mm (406 dots per in)
Number of elements
4420
896 per printhead
4440
1792 per printhead
“X” dimensions
4420
10 mil to 500 mil (0.25 mm to 12.7 mm); 5 mil (0.13
mm) in drag mode only (specified media only)
4440
5 mil to 500 mil (0.127 mm to 12.7 mm) (specified
media only); 2.5 mil (0.06 mm) in drag mode only (specified
media only)
Printing Method
The printers are capable of direct thermal (DT) printing or thermal transfer (TTR)
printing using a thermal transfer ribbon.
Printing Speed
Maximum 254 mm per second (10 inches per second), on specified media only
Minimum 51 mm per second (2 inches per second)
The print speed can be changed in 1 ips increments only. Note that the printer cannot
print at 228.6 mps (9 ips).
Ribbon Specifications
Length 450 m (18,000 linear inches)
Widths 54 mm (2.1 inches)
76 mm (3.0 inches)
104 mm (4.1 inches)
114 mm (4.5 inches)
Diameter 81 mm (3.2 inches) maximum
