EasyCoder 4420/4440 Bar Code Label Printer User’s Manual
A-4
Media Specifications
G
44XXU067.eps
D
C
A
B
E
F
H
Number Description Minimum Maximum
A Label width 13 mm (0.65 in) 111.8 mm (4.4 in)
B Backing width (or tag width) 19 mm (0.75 in) 114.3 mm (4.5 in)
C Gap between labels 2.54 mm (0.10 in) 25.4 mm (1.0 in)
D Label length - self-strip media
Label length - butt cut media
25.4 mm (1.0 in)
12.7 mm (0.5 in)
609.6 mm (24 in)
609.6 mm (24 in)
E Media thickness (including backing) 0.15 mm (0.0059 in) 0.30 mm (0.012 in)
F Reflective sensor mark length 2.54 mm (0.10 in) 12.7 mm (0.5 in)
G Notch diameter 3.18 mm (0.125 in) N/A
H Notch height (depth) 6.4 mm (0.25 in) N/A
Roll diameter 213 mm (8.38 in)
