Communications Reference

C-7

This table lists the protocol characters that you can redefine and the protocols they

affect:

Character Protocols Affected

SELECT IN POL Mode D, Multi-Drop

POLL IN POL Mode D, Multi-Drop

RES IN POL Mode D, Multi-Drop

REQ IN POL Mode D, Multi-Drop

SOM IN STD, POL Mode D, Multi-Drop, XON/XOFF

EOM IN STD, POL Mode D, Multi-Drop, XON/XOFF

AFF IN POL Mode D, Multi-Drop

NEG IN POL Mode D, Multi-Drop

DLE IN STD, POL Mode D, Multi-Drop, XON/XOFF

XON IN XON/XOFF

XOFF IN XON/XOFF

SELECT OUT Multi-Drop

POLL OUT Multi-Drop

RES OUT POL Mode D, Multi-Drop

REQ OUT POL Mode D, Multi-Drop

SOM OUT POL Mode D, Multi-Drop

EOM OUT POL Mode D, Multi-Drop

AFF OUT POL Mode D, Multi-Drop

NEG OUT STD, POL Mode D, Multi-Drop

DLE OUT STD, POL Mode D, Multi-Drop, XON/XOFF

XON OUT XON/XOFF

XOFF OUT POL Mode D, Multi-Drop, XON/XOFF

PROTO-CMD 1 STD XON/XOFF

PROTO-CMD 2 STD XON/XOFF

TIMEOUT ON EOM POL Mode D, Multi-Drop

Default Chapter5
