EasyCoder 4420/4440 Bar Code Label Printer User’s Manual
3-6
8. Use one hand to hold the printer and use the other hand to pull the cleaning card
forward until you have pulled the entire card through the media path.
9. Repeat Steps 6 through 8.
10. Dispose of the cleaning card properly.
11. If you are finished cleaning, replace the media cover.
44XXU030.eps
Label
gap
sensor
Cleaning
card
Head lift
lever
Upper
media guide
Lower
media guide
Edge
guide
To clean the printhead using a cotton swab and isopropyl alcohol
1. Turn off the printer and remove the power cord.
2. Remove the media cover.
3. Disengage the printhead by rotating the head lift lever clockwise until the printhead
releases. This raises the printhead so that you can clean it.
4. Remove the media and ribbon if necessary.
5. Use a cotton swab moistened with alcohol to remove any dirt, adhesive, or debris
from the print surface on the bottom of the printhead.
6. Wait 5 to 10 seconds for the print surface to dry. Replace the media and ribbon.
7. Engage the printhead by rotating the head lift lever counterclockwise until it locks
in place.
8. If you are finished cleaning, replace the media cover.
