Intermec EasyCoder 501 – Service Manual Ed. 7
44
Chapter 8 Print Unit
8.2 Main Parts, cont.
Liner Drive Roller
Stepper Motor
Platen Roller
Tear Bar
Printhead
Headlift Mechanism
EasyCoder 501 S, E, and SA
