45Intermec EasyCoder 501 – Service Manual Ed. 7
Chapter 8 Print Unit
Load
Load
Print
Print
Load
Print
8.2 Main Parts, cont.
Stepper Motor
Non-stick Platen Roller
Plasma-coated
Tear Bar
Plasma-coated
Surface
Headlift Mechanism
EasyCoder 501 LinerLess
Printhead
No Thermal Transfer Mechanism
No Liner Drive Roller
