44 Intermec EasyCoder PD4—User’s Guide
Chapter 6—Options
5 Attach the cutter cover onto the cutter mechanism by first connecting
the hooks on the back side of the cover over the cutter mechanism and
then locking the cover with the screw at the bottom.
6 If needed, fit the tray to the front of the cutter.
7 Install the media as described in Chapter 4 “Media Load”, section
“Tear-off (Straight-through)”. Recommended label/paper length is at
least 30 mm (1.18 in).
Note: Make sure that the printer is set to use the cutter, either
in the Setup Mode (see Chapter 7) or using an O command,
see ESim v5.xx for EasyCoder PD4, Programmer’s Reference
Manual. e label taken sensor cannot be used with the cutter.
