Intermec PM4I - Page 129

Appendix A — Specifications
PM4i Mid-Range Printer User’s Manual 115
Print Speed and Resolution
Specification Description
Print Mode Direct
Thermal Transfer
Print Speed
(variable)
100 to 150 mm/sec (4 to 6 in/sec) at 300 dpi and 406 dpi
100 to 200 mm/sec (4 to 8 in/sec) at 203 dpi
Printhead
Resolution
8 dots/mm at 203 dpi
11.8 dots/mm at 300 dpi
16 dots/mm at 406 dpi
Print Width
(max)
104 mm (4.095 in) at 203 dpi
105.7 mm (4.161 in) at 300 dpi
104.0 mm (4.095 in) at 406 dpi
Print Length
(max)
409.5 cm (161.25 in)
Media Width
(min/max)
25 to 114.3 mm (1 to 4.5 in)
Media Roll
Diameter (max)
213 mm (8.38 in)
Medial Roll Core
Diameter
38 to 40 mm (1.5 in) or 76 mm (3 in)
Ribbon Width
(min/max)
25 to 110 mm (1 to 4.33 in)
Ribbon Roll
Diameter (outer)
(max)
82 mm (3.2 in)
450 m (1475 ft) of ribbon
Ribbon Roll
Core Diameter
(inner)
25.4 mm (1.00 in)
Print Directions 4
