Appendix A — Specifications
PM4i Mid-Range Printer User’s Manual 121
Non-Adhesive Strip
Self-Adhesive Strip
Liner (b)
The liner must not extend more than a total of 1.6 mm (0.06 in)
outside the face material and should protrude equally on both sides.
Media Width Including Liner (a)
Measurement Value
Maximum 114.3 mm (4.50 in)
Minimum 25.0 mm (1.00 in)
Media Width Excluding Liner (c)
Measurement Value
Maximum 112.7 mm (4.43 in)
Minimum 23.8 mm (0.94 in)
